Capacity | |
Drilling Capacity in Steel | 40 |
Tapping Capacity in Steel | 25 |
Spindle | |
Spindle Travel | 200 |
Spindle Taper | MT-4 |
No. of Spindle Speed | 08 |
Range of Spindle Speed | 90-1690 |
Working Range | |
Column Diameter | 112.60 |
Max. Distance between Spindle Center to column Face | 270 |
Max. Distance between Spindle Nose to Working Table | 445 |
Max. Distance between Spindle Nose to Base Plate | 885 |
General | |
Size of Square Table | 418 x 418 |
Size of Base Plate | 465 x 690 |
Electric Motor | 3 Phase, 1.5 H.P. 1440 RPM |
'V'-Belt Size | B-54 |
Net Weight of Machine ( Approx. ) | 440 Kg. |
Overall Dimensions of Machine H x W x L | 1830 x 550 x 930 |
Wooden Case Dimensions H x W x L | 1900 x 600 x 1000 |
Standard Accessories : Drill Drift, Motor Pulley
Extra Accessories : Electric Motor, R/F Switch, V-belt, Drill Chuck, Arbor, Machine Lamp, Coolant Pump with Fittings, Drill Bits, Set of Spanners
