Heavy Duty Pillar Drilling Machine

The Heavy Duty Pillar Drilling Machine that we provide to our esteemed clients is widely appreciated owing to its clever design which ensures high operational fluency, impeccable performance and ease in in gear speed shifting. This is sure to fit a variety of applications as it has 2 cleverly designed spindle speeds which can be used for drilling, reaming and tapping applications. Further, owing to its rugged construction, this machine is also utilized for counter- boring, honing, reaming and other such allied service. The single column structure of this machine makes for easy centering and enhanced ease in usage. All the components of this Heavy Duty Pillar Drilling Machine are precision hardened in order to provide protection against wear and tear.
38 mm Cap Heavy Duty Pillar Drilling Machine
Get a Price/Quote

38 mm Cap Heavy Duty Pillar Drilling Machine

Price: 39000.00 - 46000.00 INR /Piece

Request To Call Back
  • Price Range 39000.00 - 46000.00 INR
  • Certifications Our Machines are manufactured & tested according to ISO standards.
  • Delivery Time 1 Week
  • FOB Port Nhava Seva, Mumbai (For Export only)
  • Minimum Order Quantity 01
  • Packaging Details Plastic Wrapping for Domestic Orders. Seaworthy Wooden Packing for Export orders with Fumigation & ISPM15 stamping.
  • Payment Terms Telegraphic Transfer (T/T)
  • Supply Ability 15 Per Week
  • Unit of Measure Piece/Pieces
  • Unit of Price Piece/Pieces

"K.M. Panchal" brand Model No. 38 TPD : 38 mm Cap. Heavy Duty Pillar Drilling Machine with Helical Gear Drive, Round Table

TECHNICAL SPECIFICATION

Parameter Specification  Drilling Capacity in Steel 38 mm Drilling Capacity in C.I. 40 mm Tapping Capacity in steel 25 mm Spindle Travel 175 mm Spindle Taper MT4 No. of Spindle Speed 8 Range of Spindle Speed 80-2600 RPM Column Diameter 112.60 mm Max. Dist. Between Spindle Center to Column Face 270 mm Max. Dist. between Spindle Nose to working table 595 mm Max. Dist. between Spindle Nose to Base Plate 1035 mm Size of Round Table Dia. 395 mm Size of Base Plate 690 x 460 mm Electric Motor Specification 1.5 HP/ 3Phase/ 1440 RPM V-Belt Size B57 Net weight of Machine 300 Kg Overall Dimensions of Machine 1760 x 730 x 560 mm   STANDARD ACCESSORIES : Drill Drift, Motor Pulley EXTRA ACCESSORIES : Electric Motor, R/F Switch, V-belt, Drill chuck, Arbor, Drill Bits, Drill Vice



Send Inquiry
19 mm Cap. 378 mm Center Pillar Drilling Machine
Get a Price/Quote

19 mm Cap. 378 mm Center Pillar Drilling Machine

Price: 26000.00 - 34000.00 INR /Piece

Request To Call Back
  • Price Range 26000.00 - 34000.00 INR
  • Certifications Our Machines are manufactured according to ISO standards and tested with same quality standards.
  • Delivery Time 1 Week
  • FOB Port Nhava Seva, Mumbai (For Export only)
  • Minimum Order Quantity 1
  • Packaging Details Plastic Wrap for Domestic supply. Seaworthy wooden packing for export orders with Fumigation & ISPM 15 stamping also.
  • Payment Terms Telegraphic Transfer (T/T)
  • Supply Ability 20 Per Week
  • Unit of Measure Piece/Pieces
  • Unit of Price Piece/Pieces

The 19 mm Cap. 378 mm Center Pillar Drilling Machine that we provide to our customers is widely appreciated in the market owing to corrosion resistance, dimensional accuracy, efficient performance, clever design, low maintenance needs and various other such factors. The offered product is widely sued in the mining and construction industry for drilling, boring and other such allied applications. Made of the best quality material, it is resistant to rust, corrosion, pressure, heat and other such applications. We provide this 19 mm Cap. 378 mm Center Pillar Drilling Machine in a  number of different specifications according like sizes, designs, working capacities and other such specifications according to the needs of our customers.

Technical Specifications & General Dimensions

Capacity
Drilling Capacity in Steel 19
Drilling Capacity in C.I. 22
Tapping Capacity in Steel 14
Spindle
Spindle Travel 130
Spindle Taper MT-2
No. of Spindle Speed 8
Range of Spindle Speed 86-3360
Working Range
Column Diameter 87
Max. Distance between Spindle Center to column Face 378
Max. Distance between Spindle Nose to Working Table 980
Max. Distance between Spindle Nose to Base Plate 585
General
Size of Square Table 395 x 395
Size of Base Plate 580 x 375
Electric Motor 3 Phase, 1 H.P. 1440 RPM
'V'-Belt Size A-57
Net Weight of Machine ( Approx. ) 205 Kg.
Overall Dimensions of Machine H x W x L 1400 x 750 x 400
Shipping Dimension 1500 x 800 x 450

Standard Accessories :
Drill Drift, Motor Pulley

Extra Accessories :
Electric Motor, R/F Switch, V-Belt, Drill Chuck, Arbor, Drill Bits, Set of Spanners, Drill Vice
Send Inquiry
25 mm Cap. 378 mm Center Pillar Drilling Machine
Get a Price/Quote

25 mm Cap. 378 mm Center Pillar Drilling Machine

Price: 33000.00 - 42000.00 INR /Piece

Request To Call Back
  • Price Range 33000.00 - 42000.00 INR
  • Certifications Our Machines are manufactured according to ISO standards and tested with same quality standards.
  • Delivery Time 1 Week
  • FOB Port Nhava Seva, Mumbai (For Export only)
  • Main Export Market(s) Asia, Australia, Middle East, Africa
  • Minimum Order Quantity 01
  • Packaging Details Plastic Wrapping for Domestic Orders. Seaworthy Wooden Packing for Export orders with Fumigation & ISPM 15 Stamping.
  • Supply Ability 10 Per Week
  • Unit of Measure Piece/Pieces
  • Unit of Price Piece/Pieces

"Pa-drill" Brand Machine Model No. 25/378PPD : 25 mm Cap. 378 mm Center Heavy Duty Pillar Drilling Machine with Square table, Helical Gear Drive and Rack-Pinion system

Technical Specifications & General Dimensions
Capacity
Drilling Capacity in Steel 25
Drilling Capacity in C.I. 30
Tapping Capacity in Steel 20
Spindle
Spindle Travel 200
Spindle Taper MT-3
No. of Spindle Speed 8
Range of Spindle Speed 115-2820
Working Range
Column Diameter 87
Max. Distance between Spindle Center to column Face 378
Max. Distance between Spindle Nose to Working Table 600
Max. Distance between Spindle Nose to Base Plate 1000
General
Size of Square Table 395 x 395
Size of Base Plate 645 x 380
Electric Motor 3 Phase, 1 H.P. 1440 RPM
'V'-Belt Size A-60
Net Weight of Machine ( Approx. )
300 Kg.
Overall Dimensions of Machine H x W x L 1770 x 725 x 470
Shipping Dimension 1950 x 750 x 520

Standard Accessories :
Drill Drift, Motor Pulley
Extra Accessories:
Electric Motor, R/F Switch, V-Belt, Drill Chuck, Arbor, Hardened Threaded Spindle.
Send Inquiry
25 mm Cap. Heavy Duty Pillar Drilling Machine
Get a Price/Quote

25 mm Cap. Heavy Duty Pillar Drilling Machine

Price: 28000.00 - 36000.00 INR /Piece

Request To Call Back
  • Price Range 28000.00 - 36000.00 INR
  • Certifications Our Products are manufactured & tested according to ISO Standards
  • Delivery Time 1 Week
  • FOB Port Nhava Seva, Mumbai (For Export only)
  • Minimum Order Quantity 01
  • Packaging Details Plastic Wrapping for Domestic Orders. Seaworthy Wooden Packing for Export Orders with Fumigation & ISPM 15 stamping.
  • Payment Terms Telegraphic Transfer (T/T)
  • Supply Ability 15 Per Week
  • Unit of Measure Piece/Pieces
  • Unit of Price Piece/Pieces

"Pa-drill" Brand Machine Model No. 25PPD: 25 mm Cap. Heavy Duty Pillar Drilling Machine with Helical gear Drilve, Square Table, Rack-Pinion System.

Technical Specifications & General Dimensions
Capacity
Drilling Capacity in Steel 25
Drilling Capacity in C.I. 30
Tapping Capacity in Steel 20
Spindle
Spindle Travel 150
Spindle Taper MT-3
No. of Spindle Speed 8
Range of Spindle Speed 115-2820
Working Range
Column Diameter 87
Max. Distance between Spindle Center to column Face 255
Max. Distance between Spindle Nose to Working Table 655
Max. Distance between Spindle Nose to Base Plate 1060
General
Size of Square Table 350 x 350
Size of Base Plate 580 x 375
Electric Motor 3 Phase, 1 H.P. 1440 RPM
'V'-Belt Size A-50
Net Weight of Machine ( Approx. ) 228 Kg.
Overall Dimensions of Machine H x W x L 1520 x 620 x 470
Shipping Dimension 1950 x 750 x 520

Standard Accessories :
Motor Pulley, Drill Drift

Extra Accessories:
Electric Motor, R/F Switch, V-Belt, Drill Chuck and Arbor, Drill Bits, Drill Vice, Set of Spanners.
Send Inquiry
38 mm Cap 378 mm Center Pillar Drilling Machine
Get a Price/Quote

38 mm Cap 378 mm Center Pillar Drilling Machine

Price: 44000.00 - 53000.00 INR /Piece

Request To Call Back
  • Price Range 44000.00 - 53000.00 INR
  • Certifications Our Machines are manufactured according to ISO standards and tested with same quality standards.
  • Delivery Time 1 Week
  • FOB Port Nhava Seva, Mumbai (For Export only)
  • Minimum Order Quantity 01
  • Packaging Details Plastic Wrapping for Domestic Orders. Seaworthy wooden packing for International orders with Fumigation and ISPM 15 stamping.
  • Payment Terms Telegraphic Transfer (T/T)
  • Supply Ability 10 Per Month
  • Unit of Measure Piece/Pieces
  • Unit of Price Piece/Pieces

Pa-drill Brand Machine Model No. 38/378 PPD : 38 mm Cap. 378 mm Center Heavy Duty Pillar Drilling Machine with Helical Gear Drive, Square Table, Rack-pinion system.

Technical Specifications & General Dimensions
Capacity
Drilling Capacity in Steel 38
Drilling Capacity in C.I. 40
Tapping Capacity in Steel 25
Spindle
Spindle Travel 200
Spindle Taper MT-4
No. of Spindle Speed 8
Range of Spindle Speed 100-2520
Working Range
Column Diameter 112.60
Max. Distance between Spindle Center to column Face 385
Max. Distance between Spindle Nose to Working Table 545
Max. Distance between Spindle Nose to Base Plate 980
General
Size of Square Table 430 x 430
Size of Base Plate 700 x 450
Electric Motor 3 Phase, 1.5 H.P. 1440 RPM
'V'-Belt Size B-64
Net Weight of Machine ( Approx. ) 425 Kg.
Overall Dimensions of Machine H x W x L 1520 x 800 x 520
Shipping Dimension 1700 x 900 x 570

Standard Accessories :
Motor Pulley, Drill Drift

Extra Accessories :
Electric Motor, R/F Switch, V-Belt, Drill Chuck and Arbor, Drill Bits, Drill Vice, Hardened Threaded Spindle.
Send Inquiry
25 MM cap 300 MM Travel Pillar Drilling Machine
Get a Price/Quote

25 MM cap 300 MM Travel Pillar Drilling Machine

Price: 33500.00 - 40200.00 INR /Piece

Request To Call Back
  • Price Range 33500.00 - 40200.00 INR
  • Certifications Our Machines are manufactured according to ISO standards and tested with same quality standards.
  • Delivery Time 1 Week
  • FOB Port Nhava Seva, Mumbai (For Export only)
  • Main Export Market(s) Asia, Australia, Middle East, Africa
  • Minimum Order Quantity 1
  • Packaging Details Plastic Wrapping for Domestic orders. Seaworthy wooden packing for Export orders with Fumigation & ISPM stamping.
  • Supply Ability 5 Per Week
  • Unit of Measure Piece/Pieces
  • Unit of Price Piece/Pieces



The 25 MM cap, 300 MM Travel Pillar Drilling Machine that we provide to our customers is widely appreciated in the market owing to its clever design, rugged construction, long service life, durable finish, excellent functional performance, shock proof functioning and various other such factors. This is widely used in the construction and mining sectors for the cutting, boring and drilling of holes in a number of different hard surface metals. Made of the best quality material, it is resistant to rust, corrosion, heat, pressure and various other such factors. This 25 MM cap, 300 MM Travel Pillar Drilling Machine can be bought from us at market leading rates with numerous easy payment options.
Technical Specifications & General Dimensions
Capacity
Drilling Capacity in Steel 25
Drilling Capacity in C.I. 30
Tapping Capacity in Steel 20
Spindle
Spindle Travel 300
Spindle Taper MT-3
No. of Spindle Speed 8
Range of Spindle Speed 115-2820
Working Range
Column Diameter 87
Max. Distance between Spindle Center to column Face 225
Max. Distance between Spindle Nose to Working Table 890
Max. Distance between Spindle Nose to Base Plate 470
General
Size of Square Table 350 x 350
Size of Base Plate 580 x 375
Electric Motor 3 Phase, 1 H.P. 1440 RPM
'V'-Belt Size A-52
Net Weight of Machine  ( Approx. ) 240 Kg.
Overall Dimensions of Machine H x W x L 1770 x 650 x 470
Shipping Dimension 1950 x 750 x 520

Standard Accessories : Motor Pulley, Drill Drift

Optional Accessories : 'V' Belt, Reversible Switch, Electric Motor, Drill Chuck & Arbor, Drill Bits, Vice, Spanners, Hardened Threaded Spindle
